Product Description Huawei Gpon ont HG8540M GPON ONT series equipments are manufactured and developed by Huawei company, which is a leader in FTTH/ FTTO broadband access network field. They are properly manageable added with features such as high-bandwidth, high reliability, low power consumption and satisfy the users requirement to access broadband, voice, data and video etc.
Huawei GPON ONU HG8540M with 4*FE/1GE+3*FE ports.
The HG8540M, an optical network terminal (ONT), is a high-end home gateway in FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users.
The HG8540M features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the HG8540M provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment.
The HG8540M Provide English firmware and EU, US, UK, AU Power adapter for your choice.
Product Features
GPON Interface: 1 *GPON interface (SC/UPC)
Transmission Rate: 2.488Gbps downstream and 1.244bps upstream
LAN: 4FE with RJ-45 connector
Technique Parameter
| Technical items | Descriptions |
| Fiber port | 1 GPON interface, 4FE/1GE+3FE,SC single-mode, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Fiber interface | SC/UPC |
| RX sensitivity | <-27dBm (1490nm) |
| WLAN | IEEE802.11b/g/n |
| LAN | 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface |
| Throughput | Downstream 950Mbps,Upstream 930Mbps |
| ONT Detection and Isolation of Active/Passive Hooligans | YES |
| DC power | Adapter input: 100-240 V AC, 50 - 60 Hz ; Adapter output: 11 - 14 V DC, 1 A |
| Button | Reset, power |
| Power | ≤8W |
| Operation | Working temperature: -0-+40ºC working humidity:5-95%(non-condensation) |
| Dimension | 280*230*80mm(length*width*height) |
| Net weight | ≤0.8Kg |
